Classify structured data using Keras preprocessing layers

View on TensorFlow.org Run in Google Colab View source on GitHub Download notebook

This tutorial demonstrates how to classify structured data, such as tabular data, using a simplified version of the PetFinder dataset from a Kaggle competition stored in a CSV file.

You will use Keras to define the model, and Keras preprocessing layers as a bridge to map from columns in a CSV file to features used to train the model. The goal is to predict if a pet will be adopted.

This tutorial contains complete code for:

  • Loading a CSV file into a DataFrame using pandas.
  • Building an input pipeline to batch and shuffle the rows using tf.data. (Visit tf.data: Build TensorFlow input pipelines for more details.)
  • Mapping from columns in the CSV file to features used to train the model with the Keras preprocessing layers.
  • Building, training, and evaluating a model using the Keras built-in methods.

The PetFinder.my mini dataset

There are several thousand rows in the PetFinder.my mini's CSV dataset file, where each row describes a pet (a dog or a cat) and each column describes an attribute, such as age, breed, color, and so on.

In the dataset's summary below, notice there are mostly numerical and categorical columns. In this tutorial, you will only be dealing with those two feature types, dropping Description (a free text feature) and AdoptionSpeed (a classification feature) during data preprocessing.

Column Pet description Feature type Data type
Type Type of animal (Dog, Cat) Categorical String
Age Age Numerical Integer
Breed1 Primary breed Categorical String
Color1 Color 1 Categorical String
Color2 Color 2 Categorical String
MaturitySize Size at maturity Categorical String
FurLength Fur length Categorical String
Vaccinated Pet has been vaccinated Categorical String
Sterilized Pet has been sterilized Categorical String
Health Health condition Categorical String
Fee Adoption fee Numerical Integer
Description Profile write-up Text String
PhotoAmt Total uploaded photos Numerical Integer
AdoptionSpeed Categorical speed of adoption Classification Integer

Import TensorFlow and other libraries

import numpy as np
import pandas as pd
import tensorflow as tf

from tensorflow.keras import layers
2024-09-05 01:20:38.599507: E external/local_xla/xla/stream_executor/cuda/cuda_fft.cc:485] Unable to register cuFFT factory: Attempting to register factory for plugin cuFFT when one has already been registered
2024-09-05 01:20:38.620596: E external/local_xla/xla/stream_executor/cuda/cuda_dnn.cc:8454] Unable to register cuDNN factory: Attempting to register factory for plugin cuDNN when one has already been registered
2024-09-05 01:20:38.626833: E external/local_xla/xla/stream_executor/cuda/cuda_blas.cc:1452] Unable to register cuBLAS factory: Attempting to register factory for plugin cuBLAS when one has already been registered
tf.__version__
'2.17.0'

Load the dataset and read it into a pandas DataFrame

pandas is a Python library with many helpful utilities for loading and working with structured data. Use tf.keras.utils.get_file to download and extract the CSV file with the PetFinder.my mini dataset, and load it into a DataFrame with pandas.read_csv:

dataset_url = 'http://storage.googleapis.com/download.tensorflow.org/data/petfinder-mini.zip'
csv_file = 'datasets/petfinder-mini/petfinder-mini.csv'

tf.keras.utils.get_file('petfinder_mini.zip', dataset_url,
                        extract=True, cache_dir='.')
dataframe = pd.read_csv(csv_file)
Downloading data from http://storage.googleapis.com/download.tensorflow.org/data/petfinder-mini.zip
1668792/1668792 ━━━━━━━━━━━━━━━━━━━━ 0s 0us/step

Inspect the dataset by checking the first five rows of the DataFrame:

dataframe.head()

Create a target variable

The original task in Kaggle's PetFinder.my Adoption Prediction competition was to predict the speed at which a pet will be adopted (e.g. in the first week, the first month, the first three months, and so on).

In this tutorial, you will simplify the task by transforming it into a binary classification problem, where you simply have to predict whether a pet was adopted or not.

After modifying the AdoptionSpeed column, 0 will indicate the pet was not adopted, and 1 will indicate it was.

# In the original dataset, `'AdoptionSpeed'` of `4` indicates
# a pet was not adopted.
dataframe['target'] = np.where(dataframe['AdoptionSpeed']==4, 0, 1)

# Drop unused features.
dataframe = dataframe.drop(columns=['AdoptionSpeed', 'Description'])

Split the DataFrame into training, validation, and test sets

The dataset is in a single pandas DataFrame. Split it into training, validation, and test sets using a, for example, 80:10:10 ratio, respectively:

train, val, test = np.split(dataframe.sample(frac=1), [int(0.8*len(dataframe)), int(0.9*len(dataframe))])
/tmpfs/src/tf_docs_env/lib/python3.9/site-packages/numpy/core/fromnumeric.py:59: FutureWarning: 'DataFrame.swapaxes' is deprecated and will be removed in a future version. Please use 'DataFrame.transpose' instead.
  return bound(*args, **kwds)
print(len(train), 'training examples')
print(len(val), 'validation examples')
print(len(test), 'test examples')
9229 training examples
1154 validation examples
1154 test examples

Create an input pipeline using tf.data

Next, create a utility function that converts each training, validation, and test set DataFrame into a tf.data.Dataset, then shuffles and batches the data.

def df_to_dataset(dataframe, shuffle=True, batch_size=32):
  df = dataframe.copy()
  labels = df.pop('target')
  df = {key: value.to_numpy()[:,tf.newaxis] for key, value in dataframe.items()}
  ds = tf.data.Dataset.from_tensor_slices((dict(df), labels))
  if shuffle:
    ds = ds.shuffle(buffer_size=len(dataframe))
  ds = ds.batch(batch_size)
  ds = ds.prefetch(batch_size)
  return ds

Now, use the newly created function (df_to_dataset) to check the format of the data the input pipeline helper function returns by calling it on the training data, and use a small batch size to keep the output readable:

batch_size = 5
train_ds = df_to_dataset(train, batch_size=batch_size)
WARNING: All log messages before absl::InitializeLog() is called are written to STDERR
I0000 00:00:1725499241.160728    9812 cuda_executor.cc:1015] successful NUMA node read from SysFS had negative value (-1), but there must be at least one NUMA node, so returning NUMA node zero. See more at https://github.com/torvalds/linux/blob/v6.0/Documentation/ABI/testing/sysfs-bus-pci#L344-L355
I0000 00:00:1725499241.164528    9812 cuda_executor.cc:1015] successful NUMA node read from SysFS had negative value (-1), but there must be at least one NUMA node, so returning NUMA node zero. See more at https://github.com/torvalds/linux/blob/v6.0/Documentation/ABI/testing/sysfs-bus-pci#L344-L355
I0000 00:00:1725499241.168293    9812 cuda_executor.cc:1015] successful NUMA node read from SysFS had negative value (-1), but there must be at least one NUMA node, so returning NUMA node zero. See more at https://github.com/torvalds/linux/blob/v6.0/Documentation/ABI/testing/sysfs-bus-pci#L344-L355
I0000 00:00:1725499241.172081    9812 cuda_executor.cc:1015] successful NUMA node read from SysFS had negative value (-1), but there must be at least one NUMA node, so returning NUMA node zero. See more at https://github.com/torvalds/linux/blob/v6.0/Documentation/ABI/testing/sysfs-bus-pci#L344-L355
I0000 00:00:1725499241.183202    9812 cuda_executor.cc:1015] successful NUMA node read from SysFS had negative value (-1), but there must be at least one NUMA node, so returning NUMA node zero. See more at https://github.com/torvalds/linux/blob/v6.0/Documentation/ABI/testing/sysfs-bus-pci#L344-L355
I0000 00:00:1725499241.186712    9812 cuda_executor.cc:1015] successful NUMA node read from SysFS had negative value (-1), but there must be at least one NUMA node, so returning NUMA node zero. See more at https://github.com/torvalds/linux/blob/v6.0/Documentation/ABI/testing/sysfs-bus-pci#L344-L355
I0000 00:00:1725499241.190256    9812 cuda_executor.cc:1015] successful NUMA node read from SysFS had negative value (-1), but there must be at least one NUMA node, so returning NUMA node zero. See more at https://github.com/torvalds/linux/blob/v6.0/Documentation/ABI/testing/sysfs-bus-pci#L344-L355
I0000 00:00:1725499241.193740    9812 cuda_executor.cc:1015] successful NUMA node read from SysFS had negative value (-1), but there must be at least one NUMA node, so returning NUMA node zero. See more at https://github.com/torvalds/linux/blob/v6.0/Documentation/ABI/testing/sysfs-bus-pci#L344-L355
I0000 00:00:1725499241.197250    9812 cuda_executor.cc:1015] successful NUMA node read from SysFS had negative value (-1), but there must be at least one NUMA node, so returning NUMA node zero. See more at https://github.com/torvalds/linux/blob/v6.0/Documentation/ABI/testing/sysfs-bus-pci#L344-L355
I0000 00:00:1725499241.200723    9812 cuda_executor.cc:1015] successful NUMA node read from SysFS had negative value (-1), but there must be at least one NUMA node, so returning NUMA node zero. See more at https://github.com/torvalds/linux/blob/v6.0/Documentation/ABI/testing/sysfs-bus-pci#L344-L355
I0000 00:00:1725499241.204294    9812 cuda_executor.cc:1015] successful NUMA node read from SysFS had negative value (-1), but there must be at least one NUMA node, so returning NUMA node zero. See more at https://github.com/torvalds/linux/blob/v6.0/Documentation/ABI/testing/sysfs-bus-pci#L344-L355
I0000 00:00:1725499241.207818    9812 cuda_executor.cc:1015] successful NUMA node read from SysFS had negative value (-1), but there must be at least one NUMA node, so returning NUMA node zero. See more at https://github.com/torvalds/linux/blob/v6.0/Documentation/ABI/testing/sysfs-bus-pci#L344-L355
I0000 00:00:1725499242.457392    9812 cuda_executor.cc:1015] successful NUMA node read from SysFS had negative value (-1), but there must be at least one NUMA node, so returning NUMA node zero. See more at https://github.com/torvalds/linux/blob/v6.0/Documentation/ABI/testing/sysfs-bus-pci#L344-L355
I0000 00:00:1725499242.459472    9812 cuda_executor.cc:1015] successful NUMA node read from SysFS had negative value (-1), but there must be at least one NUMA node, so returning NUMA node zero. See more at https://github.com/torvalds/linux/blob/v6.0/Documentation/ABI/testing/sysfs-bus-pci#L344-L355
I0000 00:00:1725499242.461579    9812 cuda_executor.cc:1015] successful NUMA node read from SysFS had negative value (-1), but there must be at least one NUMA node, so returning NUMA node zero. See more at https://github.com/torvalds/linux/blob/v6.0/Documentation/ABI/testing/sysfs-bus-pci#L344-L355
I0000 00:00:1725499242.463650    9812 cuda_executor.cc:1015] successful NUMA node read from SysFS had negative value (-1), but there must be at least one NUMA node, so returning NUMA node zero. See more at https://github.com/torvalds/linux/blob/v6.0/Documentation/ABI/testing/sysfs-bus-pci#L344-L355
I0000 00:00:1725499242.465730    9812 cuda_executor.cc:1015] successful NUMA node read from SysFS had negative value (-1), but there must be at least one NUMA node, so returning NUMA node zero. See more at https://github.com/torvalds/linux/blob/v6.0/Documentation/ABI/testing/sysfs-bus-pci#L344-L355
I0000 00:00:1725499242.467675    9812 cuda_executor.cc:1015] successful NUMA node read from SysFS had negative value (-1), but there must be at least one NUMA node, so returning NUMA node zero. See more at https://github.com/torvalds/linux/blob/v6.0/Documentation/ABI/testing/sysfs-bus-pci#L344-L355
I0000 00:00:1725499242.469695    9812 cuda_executor.cc:1015] successful NUMA node read from SysFS had negative value (-1), but there must be at least one NUMA node, so returning NUMA node zero. See more at https://github.com/torvalds/linux/blob/v6.0/Documentation/ABI/testing/sysfs-bus-pci#L344-L355
I0000 00:00:1725499242.471876    9812 cuda_executor.cc:1015] successful NUMA node read from SysFS had negative value (-1), but there must be at least one NUMA node, so returning NUMA node zero. See more at https://github.com/torvalds/linux/blob/v6.0/Documentation/ABI/testing/sysfs-bus-pci#L344-L355
I0000 00:00:1725499242.473835    9812 cuda_executor.cc:1015] successful NUMA node read from SysFS had negative value (-1), but there must be at least one NUMA node, so returning NUMA node zero. See more at https://github.com/torvalds/linux/blob/v6.0/Documentation/ABI/testing/sysfs-bus-pci#L344-L355
I0000 00:00:1725499242.475755    9812 cuda_executor.cc:1015] successful NUMA node read from SysFS had negative value (-1), but there must be at least one NUMA node, so returning NUMA node zero. See more at https://github.com/torvalds/linux/blob/v6.0/Documentation/ABI/testing/sysfs-bus-pci#L344-L355
I0000 00:00:1725499242.477755    9812 cuda_executor.cc:1015] successful NUMA node read from SysFS had negative value (-1), but there must be at least one NUMA node, so returning NUMA node zero. See more at https://github.com/torvalds/linux/blob/v6.0/Documentation/ABI/testing/sysfs-bus-pci#L344-L355
I0000 00:00:1725499242.480239    9812 cuda_executor.cc:1015] successful NUMA node read from SysFS had negative value (-1), but there must be at least one NUMA node, so returning NUMA node zero. See more at https://github.com/torvalds/linux/blob/v6.0/Documentation/ABI/testing/sysfs-bus-pci#L344-L355
I0000 00:00:1725499242.522691    9812 cuda_executor.cc:1015] successful NUMA node read from SysFS had negative value (-1), but there must be at least one NUMA node, so returning NUMA node zero. See more at https://github.com/torvalds/linux/blob/v6.0/Documentation/ABI/testing/sysfs-bus-pci#L344-L355
I0000 00:00:1725499242.524681    9812 cuda_executor.cc:1015] successful NUMA node read from SysFS had negative value (-1), but there must be at least one NUMA node, so returning NUMA node zero. See more at https://github.com/torvalds/linux/blob/v6.0/Documentation/ABI/testing/sysfs-bus-pci#L344-L355
I0000 00:00:1725499242.526832    9812 cuda_executor.cc:1015] successful NUMA node read from SysFS had negative value (-1), but there must be at least one NUMA node, so returning NUMA node zero. See more at https://github.com/torvalds/linux/blob/v6.0/Documentation/ABI/testing/sysfs-bus-pci#L344-L355
I0000 00:00:1725499242.528865    9812 cuda_executor.cc:1015] successful NUMA node read from SysFS had negative value (-1), but there must be at least one NUMA node, so returning NUMA node zero. See more at https://github.com/torvalds/linux/blob/v6.0/Documentation/ABI/testing/sysfs-bus-pci#L344-L355
I0000 00:00:1725499242.530735    9812 cuda_executor.cc:1015] successful NUMA node read from SysFS had negative value (-1), but there must be at least one NUMA node, so returning NUMA node zero. See more at https://github.com/torvalds/linux/blob/v6.0/Documentation/ABI/testing/sysfs-bus-pci#L344-L355
I0000 00:00:1725499242.532710    9812 cuda_executor.cc:1015] successful NUMA node read from SysFS had negative value (-1), but there must be at least one NUMA node, so returning NUMA node zero. See more at https://github.com/torvalds/linux/blob/v6.0/Documentation/ABI/testing/sysfs-bus-pci#L344-L355
I0000 00:00:1725499242.534711    9812 cuda_executor.cc:1015] successful NUMA node read from SysFS had negative value (-1), but there must be at least one NUMA node, so returning NUMA node zero. See more at https://github.com/torvalds/linux/blob/v6.0/Documentation/ABI/testing/sysfs-bus-pci#L344-L355
I0000 00:00:1725499242.536716    9812 cuda_executor.cc:1015] successful NUMA node read from SysFS had negative value (-1), but there must be at least one NUMA node, so returning NUMA node zero. See more at https://github.com/torvalds/linux/blob/v6.0/Documentation/ABI/testing/sysfs-bus-pci#L344-L355
I0000 00:00:1725499242.538582    9812 cuda_executor.cc:1015] successful NUMA node read from SysFS had negative value (-1), but there must be at least one NUMA node, so returning NUMA node zero. See more at https://github.com/torvalds/linux/blob/v6.0/Documentation/ABI/testing/sysfs-bus-pci#L344-L355
I0000 00:00:1725499242.542138    9812 cuda_executor.cc:1015] successful NUMA node read from SysFS had negative value (-1), but there must be at least one NUMA node, so returning NUMA node zero. See more at https://github.com/torvalds/linux/blob/v6.0/Documentation/ABI/testing/sysfs-bus-pci#L344-L355
I0000 00:00:1725499242.544598    9812 cuda_executor.cc:1015] successful NUMA node read from SysFS had negative value (-1), but there must be at least one NUMA node, so returning NUMA node zero. See more at https://github.com/torvalds/linux/blob/v6.0/Documentation/ABI/testing/sysfs-bus-pci#L344-L355
I0000 00:00:1725499242.547054    9812 cuda_executor.cc:1015] successful NUMA node read from SysFS had negative value (-1), but there must be at least one NUMA node, so returning NUMA node zero. See more at https://github.com/torvalds/linux/blob/v6.0/Documentation/ABI/testing/sysfs-bus-pci#L344-L355
[(train_features, label_batch)] = train_ds.take(1)
print('Every feature:', list(train_features.keys()))
print('A batch of ages:', train_features['Age'])
print('A batch of targets:', label_batch )
Every feature: ['Type', 'Age', 'Breed1', 'Gender', 'Color1', 'Color2', 'MaturitySize', 'FurLength', 'Vaccinated', 'Sterilized', 'Health', 'Fee', 'PhotoAmt', 'target']
A batch of ages: tf.Tensor(
[[5]
 [2]
 [2]
 [3]
 [3]], shape=(5, 1), dtype=int64)
A batch of targets: tf.Tensor([1 1 1 1 1], shape=(5,), dtype=int64)

As the output demonstrates, the training set returns a dictionary of column names (from the DataFrame) that map to column values from rows.

Apply the Keras preprocessing layers

The Keras preprocessing layers allow you to build Keras-native input processing pipelines, which can be used as independent preprocessing code in non-Keras workflows, combined directly with Keras models, and exported as part of a Keras SavedModel.

In this tutorial, you will use the following four preprocessing layers to demonstrate how to perform preprocessing, structured data encoding, and feature engineering:

You can learn more about the available layers in the Working with preprocessing layers guide.

  • For numerical features of the PetFinder.my mini dataset, you will use a tf.keras.layers.Normalization layer to standardize the distribution of the data.
  • For categorical features, such as pet Types (Dog and Cat strings), you will transform them to multi-hot encoded tensors with tf.keras.layers.CategoryEncoding.

Numerical columns

For each numeric feature in the PetFinder.my mini dataset, you will use a tf.keras.layers.Normalization layer to standardize the distribution of the data.

Define a new utility function that returns a layer which applies feature-wise normalization to numerical features using that Keras preprocessing layer:

def get_normalization_layer(name, dataset):
  # Create a Normalization layer for the feature.
  normalizer = layers.Normalization(axis=None)

  # Prepare a Dataset that only yields the feature.
  feature_ds = dataset.map(lambda x, y: x[name])

  # Learn the statistics of the data.
  normalizer.adapt(feature_ds)

  return normalizer

Next, test the new function by calling it on the total uploaded pet photo features to normalize 'PhotoAmt':

photo_count_col = train_features['PhotoAmt']
layer = get_normalization_layer('PhotoAmt', train_ds)
layer(photo_count_col)
<tf.Tensor: shape=(5, 1), dtype=float32, numpy=
array([[-0.19791041],
       [-0.82850194],
       [-0.5132062 ],
       [-0.5132062 ],
       [-0.82850194]], dtype=float32)>

Categorical columns

Pet Types in the dataset are represented as strings—Dogs and Cats—which need to be multi-hot encoded before being fed into the model. The Age feature

Define another new utility function that returns a layer which maps values from a vocabulary to integer indices and multi-hot encodes the features using the tf.keras.layers.StringLookup, tf.keras.layers.IntegerLookup, and tf.keras.CategoryEncoding preprocessing layers:

def get_category_encoding_layer(name, dataset, dtype, max_tokens=None):
  # Create a layer that turns strings into integer indices.
  if dtype == 'string':
    index = layers.StringLookup(max_tokens=max_tokens)
  # Otherwise, create a layer that turns integer values into integer indices.
  else:
    index = layers.IntegerLookup(max_tokens=max_tokens)

  # Prepare a `tf.data.Dataset` that only yields the feature.
  feature_ds = dataset.map(lambda x, y: x[name])

  # Learn the set of possible values and assign them a fixed integer index.
  index.adapt(feature_ds)

  # Encode the integer indices.
  encoder = layers.CategoryEncoding(num_tokens=index.vocabulary_size())

  # Apply multi-hot encoding to the indices. The lambda function captures the
  # layer, so you can use them, or include them in the Keras Functional model later.
  return lambda feature: encoder(index(feature))

Test the get_category_encoding_layer function by calling it on pet 'Type' features to turn them into multi-hot encoded tensors:

test_type_col = train_features['Type']
test_type_layer = get_category_encoding_layer(name='Type',
                                              dataset=train_ds,
                                              dtype='string')
test_type_layer(test_type_col)
<tf.Tensor: shape=(5, 3), dtype=float32, numpy=
array([[0., 1., 0.],
       [0., 1., 0.],
       [0., 1., 0.],
       [0., 0., 1.],
       [0., 0., 1.]], dtype=float32)>

Repeat the process on the pet 'Age' features:

test_age_col = train_features['Age']
test_age_layer = get_category_encoding_layer(name='Age',
                                             dataset=train_ds,
                                             dtype='int64',
                                             max_tokens=5)
test_age_layer(test_age_col)
<tf.Tensor: shape=(5, 5), dtype=float32, numpy=
array([[1., 0., 0., 0., 0.],
       [0., 1., 0., 0., 0.],
       [0., 1., 0., 0., 0.],
       [0., 0., 1., 0., 0.],
       [0., 0., 1., 0., 0.]], dtype=float32)>

Preprocess selected features to train the model on

You have learned how to use several types of Keras preprocessing layers. Next, you will:

  • Apply the preprocessing utility functions defined earlier on 13 numerical and categorical features from the PetFinder.my mini dataset.
  • Add all the feature inputs to a list.

As mentioned in the beginning, to train the model, you will use the PetFinder.my mini dataset's numerical ('PhotoAmt', 'Fee') and categorical ('Age', 'Type', 'Color1', 'Color2', 'Gender', 'MaturitySize', 'FurLength', 'Vaccinated', 'Sterilized', 'Health', 'Breed1') features.

Earlier, you used a small batch size to demonstrate the input pipeline. Let's now create a new input pipeline with a larger batch size of 256:

batch_size = 256
train_ds = df_to_dataset(train, batch_size=batch_size)
val_ds = df_to_dataset(val, shuffle=False, batch_size=batch_size)
test_ds = df_to_dataset(test, shuffle=False, batch_size=batch_size)

Normalize the numerical features (the number of pet photos and the adoption fee), and add them to one list of inputs called encoded_features:

all_inputs = {}
encoded_features = []

# Numerical features.
for header in ['PhotoAmt', 'Fee']:
  numeric_col = tf.keras.Input(shape=(1,), name=header)
  normalization_layer = get_normalization_layer(header, train_ds)
  encoded_numeric_col = normalization_layer(numeric_col)
  all_inputs[header] = numeric_col
  encoded_features.append(encoded_numeric_col)

Turn the integer categorical values from the dataset (the pet age) into integer indices, perform multi-hot encoding, and add the resulting feature inputs to encoded_features:

age_col = tf.keras.Input(shape=(1,), name='Age', dtype='int64')

encoding_layer = get_category_encoding_layer(name='Age',
                                             dataset=train_ds,
                                             dtype='int64',
                                             max_tokens=5)
encoded_age_col = encoding_layer(age_col)
all_inputs['Age'] = age_col
encoded_features.append(encoded_age_col)

Repeat the same step for the string categorical values:

categorical_cols = ['Type', 'Color1', 'Color2', 'Gender', 'MaturitySize',
                    'FurLength', 'Vaccinated', 'Sterilized', 'Health', 'Breed1']

for header in categorical_cols:
  categorical_col = tf.keras.Input(shape=(1,), name=header, dtype='string')
  encoding_layer = get_category_encoding_layer(name=header,
                                               dataset=train_ds,
                                               dtype='string',
                                               max_tokens=5)
  encoded_categorical_col = encoding_layer(categorical_col)
  all_inputs[header] = categorical_col
  encoded_features.append(encoded_categorical_col)

Create, compile, and train the model

The next step is to create a model using the Keras Functional API. For the first layer in your model, merge the list of feature inputs—encoded_features—into one vector via concatenation with tf.keras.layers.concatenate.

encoded_features
[<KerasTensor shape=(None, 1), dtype=float32, sparse=False, name=keras_tensor>,
 <KerasTensor shape=(None, 1), dtype=float32, sparse=False, name=keras_tensor_1>,
 <KerasTensor shape=(None, 5), dtype=float32, sparse=False, name=keras_tensor_3>,
 <KerasTensor shape=(None, 3), dtype=float32, sparse=False, name=keras_tensor_5>,
 <KerasTensor shape=(None, 5), dtype=float32, sparse=False, name=keras_tensor_7>,
 <KerasTensor shape=(None, 5), dtype=float32, sparse=False, name=keras_tensor_9>,
 <KerasTensor shape=(None, 3), dtype=float32, sparse=False, name=keras_tensor_11>,
 <KerasTensor shape=(None, 4), dtype=float32, sparse=False, name=keras_tensor_13>,
 <KerasTensor shape=(None, 4), dtype=float32, sparse=False, name=keras_tensor_15>,
 <KerasTensor shape=(None, 4), dtype=float32, sparse=False, name=keras_tensor_17>,
 <KerasTensor shape=(None, 4), dtype=float32, sparse=False, name=keras_tensor_19>,
 <KerasTensor shape=(None, 4), dtype=float32, sparse=False, name=keras_tensor_21>,
 <KerasTensor shape=(None, 5), dtype=float32, sparse=False, name=keras_tensor_23>]
all_features = tf.keras.layers.concatenate(encoded_features)
x = tf.keras.layers.Dense(32, activation="relu")(all_features)
x = tf.keras.layers.Dropout(0.5)(x)
output = tf.keras.layers.Dense(1)(x)

model = tf.keras.Model(all_inputs, output)

Configure the model with Keras Model.compile:

model.compile(optimizer='adam',
              loss=tf.keras.losses.BinaryCrossentropy(from_logits=True),
              metrics=["accuracy"],
              run_eagerly=True)

Let's visualize the connectivity graph:

# Use `rankdir='LR'` to make the graph horizontal.
tf.keras.utils.plot_model(model, show_shapes=True, show_layer_names=True, rankdir="LR")

png

Next, train and test the model:

model.fit(train_ds, epochs=10, validation_data=val_ds)
Epoch 1/10
37/37 ━━━━━━━━━━━━━━━━━━━━ 3s 56ms/step - accuracy: 0.5514 - loss: 0.6413 - val_accuracy: 0.7504 - val_loss: 0.5363
Epoch 2/10
37/37 ━━━━━━━━━━━━━━━━━━━━ 2s 54ms/step - accuracy: 0.6406 - loss: 0.5972 - val_accuracy: 0.7470 - val_loss: 0.5207
Epoch 3/10
37/37 ━━━━━━━━━━━━━━━━━━━━ 2s 54ms/step - accuracy: 0.6941 - loss: 0.5595 - val_accuracy: 0.7470 - val_loss: 0.5103
Epoch 4/10
37/37 ━━━━━━━━━━━━━━━━━━━━ 2s 54ms/step - accuracy: 0.6888 - loss: 0.5586 - val_accuracy: 0.7539 - val_loss: 0.5042
Epoch 5/10
37/37 ━━━━━━━━━━━━━━━━━━━━ 2s 53ms/step - accuracy: 0.7079 - loss: 0.5410 - val_accuracy: 0.7530 - val_loss: 0.4996
Epoch 6/10
37/37 ━━━━━━━━━━━━━━━━━━━━ 2s 53ms/step - accuracy: 0.7065 - loss: 0.5407 - val_accuracy: 0.7504 - val_loss: 0.4959
Epoch 7/10
37/37 ━━━━━━━━━━━━━━━━━━━━ 2s 52ms/step - accuracy: 0.7106 - loss: 0.5370 - val_accuracy: 0.7556 - val_loss: 0.4941
Epoch 8/10
37/37 ━━━━━━━━━━━━━━━━━━━━ 2s 54ms/step - accuracy: 0.7131 - loss: 0.5302 - val_accuracy: 0.7591 - val_loss: 0.4922
Epoch 9/10
37/37 ━━━━━━━━━━━━━━━━━━━━ 2s 53ms/step - accuracy: 0.7216 - loss: 0.5289 - val_accuracy: 0.7582 - val_loss: 0.4908
Epoch 10/10
37/37 ━━━━━━━━━━━━━━━━━━━━ 2s 53ms/step - accuracy: 0.7211 - loss: 0.5266 - val_accuracy: 0.7574 - val_loss: 0.4899
<keras.src.callbacks.history.History at 0x7f2b280947f0>
result = model.evaluate(test_ds, return_dict=True)
print(result)
5/5 ━━━━━━━━━━━━━━━━━━━━ 0s 25ms/step - accuracy: 0.7408 - loss: 0.5098
{'accuracy': 0.737434983253479, 'loss': 0.5158435702323914}

Perform inference

The model you have developed can now classify a row from a CSV file directly after you've included the preprocessing layers inside the model itself.

You can now save and reload the Keras model with Model.save and Model.load_model before performing inference on new data:

model.save('my_pet_classifier.keras')
reloaded_model = tf.keras.models.load_model('my_pet_classifier.keras')

To get a prediction for a new sample, you can simply call the Keras Model.predict method. There are just two things you need to do:

  1. Wrap scalars into a list so as to have a batch dimension (Models only process batches of data, not single samples).
  2. Call tf.convert_to_tensor on each feature.
sample = {
    'Type': 'Cat',
    'Age': 3,
    'Breed1': 'Tabby',
    'Gender': 'Male',
    'Color1': 'Black',
    'Color2': 'White',
    'MaturitySize': 'Small',
    'FurLength': 'Short',
    'Vaccinated': 'No',
    'Sterilized': 'No',
    'Health': 'Healthy',
    'Fee': 100,
    'PhotoAmt': 2,
}

input_dict = {name: tf.convert_to_tensor([value]) for name, value in sample.items()}
predictions = reloaded_model.predict(input_dict)
prob = tf.nn.sigmoid(predictions[0])

print(
    "This particular pet had a %.1f percent probability "
    "of getting adopted." % (100 * prob)
)
1/1 ━━━━━━━━━━━━━━━━━━━━ 0s 73ms/step
This particular pet had a 81.0 percent probability of getting adopted.

Next steps

To learn more about classifying structured data, try working with other datasets. To improve accuracy during training and testing your models, think carefully about which features to include in your model and how they should be represented.

Below are some suggestions for datasets:

  • TensorFlow Datasets: MovieLens: A set of movie ratings from a movie recommendation service.
  • TensorFlow Datasets: Wine Quality: Two datasets related to red and white variants of the Portuguese "Vinho Verde" wine. You can also find the Red Wine Quality dataset on Kaggle.
  • Kaggle: arXiv Dataset: A corpus of 1.7 million scholarly articles from arXiv, covering physics, computer science, math, statistics, electrical engineering, quantitative biology, and economics.
